Key Features:
Thomas compressor/4Bar pressure/PSA Technology
Features:
I. Thomas compressor;
II. 4 bar pressure compatible with ventilator or anaesthesia machine;
III. PSA technology-safe, convenient, economical;
IV. Born for ICU and operating room.
Applications:
I. High pressure oxygen concentrator with air vacuum used for hospital patient beds,for patient sputum aspiration;
II. Oxygen Concentrator with air vacuum used in operating room,used for suctioned out large quantities of fluid during surgical operations;
III. It could be applied to ventilator and anaesthesia machine at ICU;
IV. It could be applied to ventilator and anaesthesia machine at operating room;
V. This machine widely used for emergency room and treatment room.
Specification:
Model | Dimension | Weight | Mains | Power consumption | Switch-on current | Output pressure | Oxygen flow | Compressor air flow | Oxygen concentration | Vacuum | Noise level | Pressure gauge | Alarms |
Type 20 | 800*440*660 | 110kgs | 220V AC, 50/60 Hz | 1200W | 7.0 A | 60Psi | Max. 10l/m | Max. 30l/m | 93%±3% | 0...-0.7 bar | ≤60 dB | AIR, O2, VAC | Low purity, High temperature, High&low pressure, Power failure |
Model | Dimension | Weight | Mains | Power consumption | Switch-on current | Output pressure | Oxygen flow | Compressor air flow | Oxygen concentration | Vacuum | Noise level | Pressure gauge | Alarms |
Type 50 | 720*630*740 | 120kgs | 220V AC, 50/60 Hz | 1600W | 7.0 A | 50Psi | Max. 10l/m | Max. 50l/m | 93%±3% | 0...-0.7 bar | ≤60 dB | AIR, O2, VAC | Low purity, High temperature, High&low pressure, Power failure |
